Name: Road

Display Field: fullname

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description:

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 500000.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -1829134.3803000003
YMin: 2337845.193599999
XMax: -629868.4135999978
YMax: 3784884.671
Spatial Reference: 102002  (102002)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 2
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• centerlineid ( type: esriFieldTypeInteger, alias: Centerline ID )
• rclnguid ( type: esriFieldTypeString, alias: NENA Global ID, length: 254 )
• discrpagid ( type: esriFieldTypeString, alias: Discrepancy Agency ID, length: 75 )
• roadnameid ( type: esriFieldTypeInteger, alias: Road Name ID )
• rangeprefixleft ( type: esriFieldTypeString, alias: Left Address Number Prefix, length: 15 )
• fromleft ( type: esriFieldTypeInteger, alias: Left From Address )
• toleft ( type: esriFieldTypeInteger, alias: Left To Address )
• parityleft ( type: esriFieldTypeString, alias: Parity Left, length: 17 , Coded Values: [Odd: Odd] , [Even: Even] , [Both: Both] , ...1 more... )
• rangeprefixright ( type: esriFieldTypeString, alias: Right Address Number Prefix, length: 15 )
• fromright ( type: esriFieldTypeInteger, alias: Right From Address )
• toright ( type: esriFieldTypeInteger, alias: Right To Address )
• parityright ( type: esriFieldTypeString, alias: Parity Right, length: 17 , Coded Values: [Odd: Odd] , [Even: Even] , [Both: Both] , ...1 more... )
• fullname ( type: esriFieldTypeString, alias: Full Road Name, length: 300 )
• fedroute ( type: esriFieldTypeString, alias: Federal Route, length: 10 )
• fedrtetype ( type: esriFieldTypeString, alias: Federal Route Type, length: 20 , Coded Values: [Freeway: Freeway] , [Highway: Highway] , [Interstate: Interstate] , ...2 more... )
• afedrte ( type: esriFieldTypeString, alias: Alternate Federal Route, length: 10 )
• afedrtetype ( type: esriFieldTypeString, alias: Alternate Federal Route Type, length: 20 , Coded Values: [Freeway: Freeway] , [Highway: Highway] , [Interstate: Interstate] , ...2 more... )
• pvtrroute ( type: esriFieldTypeString, alias: Provincial/Territorial Route, length: 10 )
• pvtrrtetype ( type: esriFieldTypeString, alias: Provincial/Territorial Route Type, length: 20 , Coded Values: [Freeway: Freeway] , [Highway: Highway] , [Interstate: Interstate] , ...2 more... )
• apvtrrte ( type: esriFieldTypeString, alias: Alternate Provincial/Territorial Route, length: 10 )
• apvtrrtetype ( type: esriFieldTypeString, alias: Alternate Provincial/Territorial Route Type, length: 20 , Coded Values: [Freeway: Freeway] , [Highway: Highway] , [Interstate: Interstate] , ...2 more... )
• ctyroute ( type: esriFieldTypeString, alias: County Route, length: 10 )
• onewaydir ( type: esriFieldTypeString, alias: One Way Indicator, length: 10 , Coded Values: [From-To: From-To] , [To-From: To-From] , [Unknown: Unknown] )
• roadlevel ( type: esriFieldTypeInteger, alias: Above or Below Grade , Coded Values: [-2: Second Subsurface] , [-1: Subsurface] , [0: Ground Level] , ...4 more... )
• inwater ( type: esriFieldTypeString, alias: In Water, length: 5 , Coded Values: [Yes: Yes] , [No: No] )
• roadclass ( type: esriFieldTypeString, alias: Road Class, length: 7 , Coded Values: [RARTLIN: RARTLIN] , [RBRGLIN: RBRGLIN] , [RFERLIN: RFERLIN] , ...8 more... )
• countryleft ( type: esriFieldTypeString, alias: Country on Left, length: 2 )
• countryright ( type: esriFieldTypeString, alias: Country on Right, length: 2 )
• pvtrleft ( type: esriFieldTypeString, alias: Province/Territory on Left, length: 2 , Coded Values: [AB: AB] , [BC: BC] , [MB: MB] , ...10 more... )
• pvtrright ( type: esriFieldTypeString, alias: Province/Territory on Right, length: 2 , Coded Values: [AB: AB] , [BC: BC] , [MB: MB] , ...10 more... )
• countyleft ( type: esriFieldTypeString, alias: County on Left, length: 40 )
• countyright ( type: esriFieldTypeString, alias: County on Right, length: 40 )
• munileft ( type: esriFieldTypeString, alias: Municipality on Left, length: 100 )
• muniright ( type: esriFieldTypeString, alias: Municipality on Right, length: 100 )
• postleft ( type: esriFieldTypeString, alias: Postal Code on Left, length: 6 )
• postright ( type: esriFieldTypeString, alias: Postal Code on Right, length: 6 )
• msagleft ( type: esriFieldTypeString, alias: MSAG on Left, length: 35 )
• msagright ( type: esriFieldTypeString, alias: MSAG on Right, length: 35 )
• esnleft ( type: esriFieldTypeString, alias: ESN on Left, length: 5 )
• esnright ( type: esriFieldTypeString, alias: ESN on Right, length: 5 )
• surface ( type: esriFieldTypeString, alias: Road Surface, length: 50 )
• dataprovider ( type: esriFieldTypeString, alias: Data Provider, length: 50 )
• accuracy ( type: esriFieldTypeSmallInteger, alias: Accuracy )
• capdate ( type: esriFieldTypeDate, alias: Capture Date, length: 8 )
• capyear ( type: esriFieldTypeSmallInteger, alias: Capture Year )
• acqtech ( type: esriFieldTypeString, alias: Data Acquisition Technique, length: 50 )
• dc_startdate ( type: esriFieldTypeDate, alias: Start Date, length: 8 )
• dc_enddate ( type: esriFieldTypeDate, alias: End Date, length: 8 )
• notes ( type: esriFieldTypeString, alias: Notes, length: 254 )
• pha_roadname ( type: esriFieldTypeString, alias: Public Highways Act Road Name, length: 50 )
• pha_class ( type: esriFieldTypeString, alias: Public Highways Act Road Class, length: 15 )
• pha_roww ( type: esriFieldTypeDouble, alias: Public Highways Act Right-Of-Way Width )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• created_user ( type: esriFieldTypeString, alias: created_user, length: 255 )
• created_date ( type: esriFieldTypeDate, alias: created_date, length: 8 )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, length: 255 )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, length: 8 )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )

Relationships:

• sd.DBO.LOC_MACA_CA_SiteAddressPoint_OPS (1) -- Related To: NWT Civic Address Point (25)
• sd.DBO.LOC_MACA_CA_AliasRoadName_OPS (3) -- Related To: Alias Road Name Table (33)
• sd.DBO.LOC_MACA_CA_MasterRoadName_OPS (4) -- Related To: Master Road Name Table (34)

Supported Operations:   Query   Query Attachments   Query Analytic   Query Related Records   Generate Renderer   Return Updates
